Engagement/Resource/Standards & Referentials

Standards &referentials,SIA · Eurocodes · FIDIC.

Command of normative frameworks is a condition of facade-advisory credibility and an operational requirement on every engineering mission. We operate across three jurisdictions simultaneously, Switzerland, continental Europe, international standards, with the capacity to translate between frames when a single project crosses several regulatory regimes.

Normative triptych, three international standards with stainless rule and welded sectionEN.059
FIG. 01 BISThree activable normative frames, equivalences documented across referentials, explicit translation when a project crosses several jurisdictions.
Atelier Shili & Partners
03jurisdictions
CH · EU · International
60+standards
mastered and activable
04phases
design · tendering · execution · handover
ESGframes
EU Taxonomy · CSRD · MEES · Minergie
01· Plate, three mastered jurisdictions

Normative frameworks mastered.

Three geographic zones define our current facade standards SIA Eurocodes perimeter, Switzerland, continental Europe, international standards. Each zone with its own referentials and documented interoperabilities.

§ TLDR · 01Switzerland · SIA · MoPEC · CECB.
§ TLDR · 02Europe · Eurocodes · DTU.
§ TLDR · 03International · FIDIC · ASTM.
§ TLDR · 04ESG · EU Taxonomy · CSRD · MEES.
§ Switzerland§ Europe§ International
§ Zone 01

Switzerland

SIA, MoPEC, CECB, Minergie, SNBS, cantonal and federal frame. Totalunternehmer contractual modes dominant on commercial and institutional Swiss real estate.

→ SIA 118/329/380/2040
§ Zone 02

Europe

Eurocodes, EN, DTU, VOB/B, RE2020, EPBD, continental frame. Plus ESG directives (EU Taxonomy, CSRD, SFDR, UK MEES) binding on institutional investors.

→ Eurocodes · DTU · RE2020
§ Zone 03

International

FIDIC (Red/Yellow/Silver/Gold), ASTM, AAMA, ISO, BS, NFPA, ETAG, international project frame. Plus environmental certifications LEED, BREEAM, WELL, DGNB by jurisdiction.

→ FIDIC · ASTM · AAMA
§ Layer 01
Switzerland
Contractual
SIA 118 · general conditions for construction works. SIA 118/329 · curtain wall and cladding clauses. Totalunternehmer · dominant total-contractor agreement.
Envelope technical
SIA 329 · technical standard for curtain walls.
Energy · carbon
SIA 380/1 · thermal energy. SIA 2040 · carbon energy (2000-watt pathway). MoPEC 2014/2025 · cantonal prescriptions. CECB · CECB+ · Cantonal Building Energy Certificate. Minergie · Minergie-P · Minergie-P-ECO · performance labels. SNBS · Standard Nachhaltiges Bauen Schweiz.
↕ Interoperability bridges · EN ↔ SIA equivalences documented
§ Layer 02
Europe
Structural calculation
Eurocodes 0 to 9 · European calculation reference.
Envelope technical
EN 13830 · curtain walls. EN 14351 · external windows / doors. EN 12354 · acoustics. EN 12152 · 12153 · air permeability / water tightness. EN 12665 · 13829 · lighting / air tightness. EN 1627 (RC1-RC6) · anti-intrusion. EN 356 · security glazing.
National (FR · DE)
DTU 33.1 · 33.2 · 39 · light facades, ETICS, glazing. VOB/B · German contractual frame. RE2020 · French environmental regulation. Décret tertiaire (DEET) · French tertiary energy reduction. MaPrimeRénov' · CEE · renovation financing dispositives.
ESG · investors
EPBD · energy performance of buildings directive. EU Taxonomy · CSRD · SFDR · sustainable finance frames. MEES · UK Minimum Energy Efficiency Standards.
↕ Interoperability bridges · ASTM ↔ EN equivalences documented
§ Layer 03
International
International contractual
FIDIC Red Book · owner carries design. FIDIC Yellow Book · Plant and Design-Build. FIDIC Silver Book · EPC / Turnkey. FIDIC Gold Book · Design-Build-Operate.
Tests · in-situ
ASTM E1105 · in-situ water tightness. AAMA 501.1 · 501.2 · 503 · curtain wall dynamic / static / acceptance. ISO 140 · acoustic performance. ISO 16933 · blast resistance.
Safety · fire
UFC 4-010-01 · US Department of Defense Antiterrorism. NFPA 285 · facade fire propagation US. BS 8414 · cladding fire propagation UK.
Structural glass · certifications
ETAG 002 · EAD 090010-00-0404 · EU structural silicone glazing frames. LEED · BREEAM · WELL · Living Building · HQE · DGNB · Estidama · Al Sa'fat · Dubai Green · environmental certifications by jurisdiction.
02· Plate, multi-jurisdiction as advantage

Multi-jurisdiction as an advantage.

Simultaneous command of Swiss, continental European and international frames is a competitive advantage on several client configurations.

Multi-jurisdiction matrix, four columns of international normative frameworksFIG. 03
FIG. 03 BISFour client configurations where multi-jurisdictional construction standards mastery creates a direct commercial advantage : international owners, GCs across multi-AO, signature architects exporting, facade contractors internationalising.
Atelier Shili & Partners
§ TLDR · 01Multi-country owners · portfolio coherence.
§ TLDR · 02GCs multi-AO · activable spec.
§ TLDR · 03Architects exporting · translate intent.
§ TLDR · 04Facade contractors · normative capability.

§ 01International owners across multiple countries

For international owners building in Switzerland, France and Germany across a single portfolio, we carry cross-jurisdictional normative coherence, Swiss MoPEC energy standards, French décret tertiaire and German GEG call for aligned but not identical technical strategies. We map the requirements and arbitrate the common solution that satisfies each jurisdiction without over-engineering.

§ 02GC and TC across multiple tenders

For general and total contractors responding to tenders across multiple jurisdictions, we provide the capacity to structure a facade-package specification activable in each context, the same base technical specification, the same performance requirements, but the normative references that apply locally. The gain is direct on the internal engineering team's productivity and on the consistency of the commercial strategy.

§ 03Signature architects exporting

For signature architects exporting their practice abroad, we are the interlocutor translating an intent born in an origin normative frame toward the constraints of a target jurisdiction. The technical feasibility of a double-skin facade designed for Switzerland is not the same in London, Milan or Singapore, performance frames, fire requirements and local codes change, and they must be arbitrated upstream so intent is preserved.

§ 04Facade contractors internationalising

For facade contractors internationalising their practice, we support the normative capability build-up of technical teams, not only on compliance calculations, but on the understanding of interactions between standards and local contractual practices. A European facade contractor responding to an RFP in Riyadh or Singapore discovers that the same technical performance is documented differently, with distinct test protocols, distinct validation authorities, and instruction timelines that can shift the project schedule by several months if poorly anticipated.

§ 05Anatomy of a multi-jurisdictional dossier

On a typical multi-jurisdictional project (e.g. an institutional headquarters in Geneva with a British owner, an Italian mandating architect and a Swiss GC), the normative dossier comprises four layered tiers. First tier : compliance with the local cantonal frame (SIA, MoPEC, communal requirements). Second tier : contractual requirements of the institutional owner (often aligned on UK MEES, BREEAM or WELL if required on top of local frame). Third tier : preferred standards of the mandating architect (often EN or DTU for Italian or French practice). Fourth tier : industrial manufacturers' standards (often ETAG or EAD for structural glazing, AAMA for North-American suppliers). Coherence between the four tiers is never automatic, and that is precisely the coherence work we bring.

§ 06The competitive advantage quantified

Quantifying the advantage of multi-jurisdictional construction standards mastery is hard in the abstract, but easy in a real project. An international project on the order of 80 to 200 M€ of envelope, poorly framed normatively, typically generates two to four requests for additional information or modifications at authority validation, each costing 20 to 80 calendar days and 50 to 200 k€ of additional studies. Well framed, the same project clears validation at the first submission. The economic difference on a single project repays the cost of an upstream normative framing by an engineering consultancy mastering the relevant jurisdictions several times over.

§ Competitive advantage
Mapping + arbitration + translation across frames = same base specification, locally-applicable normative references. Coherence + productivity.
03· Plate, four project-phase activations

The right framework at the right time.

Activation of a referential is not the same at each project phase. Four phases, design, tendering, execution, handover, each with its own referentials and deliverables.

01 / 04Design

Design (SD · DD · tender design).

Integration of requirements from sketch phase, far cheaper than at execution.

Integration of normative requirements from sketch phase. The regulatory frame, MoPEC, SIA 380/1 or RE2020 thermal performance, fire resistance by typology, Eurocode 1 wind, drives structural and material choices that are far cheaper to integrate at sketch phase than at tender or execution phase.

SD/DD/TenderMoPECEurocode 1
02 / 04Tendering

Consultation and tendering.

Spec with right references, reduces ambiguity, protects owner against claims.

Drafting facade-package specifications with the right normative references. A specification that cites the relevant standards, with expected performance precisions and applicable test protocols, reduces contractual ambiguity and protects the owner against recourse or claims. Conversely, a specification vague on frameworks opens negotiation angles that responding contractors will exploit.

SpecNorm. referencesTest protocols
03 / 04Execution

Execution (QC against standards).

Compliance validation, ASTM E1105, AAMA 501.2, EN 13829, ISO 140, IR thermography.

Compliance validation in production and on site. Factory test plans per ASTM E1105 or EN 12152, on-site controls per AAMA 501.2 or EN 13829, infrared thermography at handover, acoustic controls per ISO 140. Each cited test refers to a precise protocol, execution quality is measured by documented compliance with these protocols.

ASTM E1105AAMA 501.2EN 13829ISO 140
04 / 04Handover

Handover (dossier + warranties).

Documented compliance demonstration, test reports, calculations, performance declarations, fire classification.

Documented compliance demonstration. The handover dossier gathers test reports, compliance calculations, performance declarations, fire-classification certificates, component datasheets. Its quality determines the ease of contractual management over the ten years of decennial warranty or equivalents.

Handover dossierDecennialFire class.
04· Plate, neutrality in the face of standards

Neutrality in the face of standards.

We apply standards. We do not hide behind them. A standard is a regulatory minimum, not an objective. Our counsel often aims to exceed regulatory requirements where exceedance creates value, or to derogate where the standard is ill-adapted.

§ 05A standard is a regulatory minimum

A standard is a regulatory minimum, not an objective. Our counsel often aims to exceed regulatory requirements where the exceedance creates value : superior energy performance reducing operational charges, fire safety beyond code protecting the owner's brand in case of event, increased durability extending the useful service life. Justified exceedance is documented in an arbitration note exposing the marginal cost, the patrimonial benefit and the return-on-investment trajectory.

§ 06Justified derogations

A standard can also be ill-adapted to a specific project, typically on architectural configurations unforeseen by standards, complex geometries where normative tests do not cover the real case, emerging technological verticals where regulation has not followed innovation. In these cases, we propose derogations justified by deep technical analysis, with agreement of competent authorities, Swiss external inspection body, French avis technique, UK building control, local authority per jurisdiction. The derogation is documented by a full technical dossier exposing performance equivalence against the applicable standard.

A normative derogation is not a license to circumvent ; it is a negotiated demonstration of equivalent performance. The dossier we produce makes the equivalence auditable, by the validating authority at instruction, by the owner at handover, and by any third party in case of dispute over the project's lifecycle.
Active neutrality

Neither literal-compliance cult nor opportunistic circumvention. This is the mark of a normative frame mobilised in service of the project, not in lieu of engineering. The posture demands an experienced engineering consultancy that knows when to apply strictly, when to exceed, and when to derogate ; and that knows above all that these three choices are contradictory if technical justification is not documented at each step.

05· Plate, three-phase mission activation

How we activate standards on a mandate.

Activation of the normative frame on a mission follows a three-phase logic, upstream framing, integration in deliverables, ongoing watch over the project duration.

§ 07First phase, upstream normative framing

From mission kick-off, we establish the map of frameworks applicable to the project, principal jurisdiction, additional jurisdictions if the owner is international, voluntary frameworks activated by ESG strategy (LEED, BREEAM, Minergie label, DGNB). This map is a deliverable validated explicitly with the client before any engineering work.

§ 08Second phase, integration in deliverables

Engineering notes, specifications, execution drawings, test reports explicitly cite the activated frameworks and the applied protocols. Equivalences between frameworks, for instance between an EN 12152 permeability class and an ASTM E283 protocol, are documented where the project crosses multiple regimes.

§ 09Third phase, ongoing normative watch

Frameworks evolve, MoPEC 2025 differs from MoPEC 2014, RE2020 replaces RT2012, Eurocodes undergo periodic revisions, ESG certifications update regularly. On projects exceeding twelve months, we track the relevant evolutions and propose the necessary adjustments before they become constraints at execution or handover phase. See also Technical Engineering for compliance calculation detail, and Carbon strategy for environmental frameworks.

§ 10Contractual discipline against normative evolution

Any normative evolution mid-project raises a contractual question : who carries the cost of the update? Our standard Owner's Engineer or LEC mission clause integrates an explicit allocation : for structural regulatory evolutions (energy, fire safety, accessibility), the update is instructed contradictorily with the owner and priced separately ; for evolutions of test protocols or voluntary frameworks (BREEAM, LEED), we integrate the evolution within the current perimeter when the update gap is reasonable.

§ 11Articulation with the chosen contractual mode

Normative application differs by contractual mode. As Owner's Engineer, the firm validates compliance owner-side, implying a critical posture vis-à-vis the contracting consortium. As Lead Envelope Consultant in direct contract, the firm carries technical compliance in the front line. In a Design-Build consortium, normative compliance is shared among consortium members with a responsibility matrix defined upfront. Fine knowledge of the chosen contractual mode therefore conditions the normative approach.

§ Three phases in cycle
Upstream framing + deliverable integration + ongoing normative watch, frameworks evolve, activation evolves with them.
06· Plate, articulation with trusted-third-party DNA

Articulation with the trusted-third-party DNA.

Mastery of facade standards SIA Eurocodes is not an isolated technical competence, it articulates with our structural DNA : trusted third party, technological neutrality, alignment with the project's interest. A standard well applied within a frame of neutrality produces a fundamentally different result from a standard applied by an engineering consultancy captive to a manufacturer.

§ Pivot equation
Mastery of facade standards SIA Eurocodes + multi-jurisdictional construction standards + trusted-third-party DNA = normative arbitration in service of the project, not the supplier.
NORMATIVE NEUTRALITY

Standards are not neutral, but our application is.

SIA 329 curtain wall, SIA 118 construction, SIA 380/1 thermal energy, Eurocodes facade, DTU 33.1 curtain wall, FIDIC Red Yellow Silver, MoPEC Minergie CECB are frames written by committees where some industrial interests are represented. Our role is not to contest them, but to apply them with discernment, arbitrating between the letter of the text, the intent of the legislator or technical committee, and the operational interest of the client's project. This stance demands the same neutrality as the rest of our practice : no manufacturer affiliation, no commission on recommended solutions, no interest capture on normative arbitrations. See the trusted-third-party DNA and the technological neutrality.

§ 12Three zones of normative arbitration

Arbitration between letter and intent appears in three recurring zones. First zone, performance requirements that contradict the designer's intent ; e.g. a normative light-transmission calculation that does not capture the chromatic quality perceived by the user. Second zone, test protocols that do not cover the actual geometry ; EN 12152 tests on standard dimensions vs the geometry of a 4×6 m jumbo glazing pattern require a derogation by equivalent analysis. Third zone, ESG certifications that penalise what they should reward ; LCA calculations can score a durable but lifecycle-performant envelope unfavourably.

§ 13Discipline of normative derogation facade

On normative derogation facade, our method is codified. First principle : no derogation without a complete technical dossier, signed by an independent engineering consultancy and validated by the competent authority. Second principle : no derogation without measurable, auditable demonstration of performance equivalence. Third principle : no derogation without durable archiving of the justification dossier (a project being received ten years later must be able to trace the origin of a derogation granted at design). This discipline protects the owner in case of dispute, the architect in case of challenge, and ourselves in case of subsequent audit.

§ 14Exceedance creates value

Justified exceedance of regulatory minima is an editorial act as much as a technical one. Energy performance superior to MoPEC or RE2020 thresholds is not only an ESG argument ; it reduces operational charges over thirty years and protects asset value against regulatory evolution (an asset already past the future threshold incurs no upgrade cost). Fire safety beyond code on a residential tower increases construction cost only by 1 to 3 %, but it protects the owner's brand in case of event, which on a patrimonial portfolio can represent hundreds of millions in brand value. The justification of exceedance is therefore as much an ROI calculation as a technical note.

07· Plate, continue reading

Continue reading.

Seven entry points to explore the engagement modes where this normative frame applies, the underlying DNA, and the adjacent project-engineering services.

A multi-jurisdictional project to frame?

An international project crossing several normative regimes, a facade-package specification to draft in a new regulatory frame, a normative derogation to instruct, describe the project and the jurisdictions concerned. We come back with a read on the applicable normative frame before any engineering proposal.

Describe the project
